DDK-LED T8 24W 1500 TUV series

  • Work Image
  • Work Image
  • Work Image
  • Work Image

DDK-LED T8 24W 1500 TUV series

DOWNLOAD DOCUMENTS

DATASHEET (PDF)

Basic parameters
  • Input power
  • Lamp holder
  • IP Rating
  • Luminous flux
  • Beam Angle
  • CRI (Ra>)
  • CCT
  • Material
  • Dimensions ø
  • Lifetime
  • Warranty (years)
  • Input voltage
  • Certification
  • Photometric test
  • Photometric Lab.
  • 24W
  • G13
  • IP50
  • 2520 Lm
  • 130°
  • >80
  • 5000K
  • Aluminium+PC(Milk)
  • Ø25,5x1488mm
  • > 80 000 hrs
  • 3 years
  • AC180-264V 50-60Hz
  • CE, PSE, RoHS, SAA, UL
  • acc.STN EN 13032
  • Skúšobňa FEI STU, Ilkovičova 3, BA
DDK-LED FL
features

Instant on/off
Energy class A+
No UV flickering
Short circuit protection
Long lifespan, High light efficiency
No glare, no mercury, no UV or IR radiation
120° Adjustable beam angle for special applications
Special optical design, lighting distribution uniformity
Energy savings of 50% compared to traditional T8 fluorescent lamps

applications

Replacement for conventional T8 fluorescent tubes
Hotels
Conference/meeting room
Commercial Areas
Residential/Institution Buildings
Schools
Hospitals

USED IN PROJECTS

DDK Slovakia
Energy saving 63% , Return on investment 3 years
